Agitation | Drive | Top drive motor(mechanical drive) |
Range | 50~1,200 rpm | |
Impeller | 2-Rushton turbine impeller, 1-foam breaker | |
Temperature | Range & Sensor | Ambient + 3。C~80。C, RTD(Pt-100), PID control |
Aeration | Sparger & Gas mode | Ring sparger(Round Type), 2gas and 4 gas Mixer(Option) |
Inlet Filter | 0.2㎛ air filter cartridge | |
Exhaust system | Filter & Condenser | 0.2㎛ air filter, SUS 316 Condenser |
pH | Range | 2.0~12.0 pH of set point, PID control |
Electrode | Gel Type | |
DO | Range | 0~200%, PID control |
Electrode | Polarographic Type | |
Anti-foam | Electrode | Conductivity Type |
Peristaltic Pumps | Control | 4 constant speed pumps each assignable to a wide variety of function fo control of acid, base, foam and feed |
Recording | pH, DO, Temp, Foam, Agitation, Peristaltic pump, etc. | |
Dimension | 550(W) x 480(L) x 550(H) (Single Vessel 5L), Controller Size : 220(W) x 478(L) x 445(H)) | |
Voltage | 220V, 1Ø, 50/60Hz, 0.6kW | |
Weight | 35kg (Controller : 20kg, Vessel 5L 1set : 15kg) |
* Please note that technical specifications subject to change.
